Description

The GenCut GL 120XY has a large 120mm diameter maximum cutting capacity equipped with a fully automated XY table. Equipped with a double hood fully enclosed structure for the safest operation along with quick clamping mechanisms to achieve the most efficient cutting processes.

A powerful cooling system with two coolant lines reduce the ability for the specimen to get too hot during the cutting process. This ensures the specimen remains intact without any deformity or burn residue. It also allows the GenCut GL 120XY to achieve the best cutting quality while increasing the utilisation rate of the cutting wheel and maximizing the life of the blades.

GenCut GL 120XY Technical Specifications

Model

GenCut GL120XY

Cutting Wheel

Φ350×2.5×Φ32mm

Maximum Cutting Section

Φ120mm

Cutting Table Size

400 x 300mm

Z-Axis (Cutting Blade Spindle Drop Distance)

150mm

Y-Axis Movement Stroke

300mm

Y-Directional Speed of the Table

0-300mm/min

X-Axis Travel

100mm

Effective Tool Fed Distance

300mm

Variable Speed

500-3000rpm

Control System

7” Colour Touch Screen Panel, PLC Controller

Cutting Modes
Flat Push Cutting, Intermittent Cutting

Cutting Speeds
1-100mm/min

Resetting Mode
Automatic

Cooling System
Automatic Water Cooling - 2 Lines

Machine Type
Vertical Cutting

Input Power
4kW

Input Voltage
380V 50/60Hz - 3Phase

GenCut GL 120XY Standard Configuration

  • GenCut GL120XY Cutting Saw

  • Coolant Chamber

  • Wrench 13#-15#

  • Wrench 17#-19#

  • Internal Hexagonal Wrench 6mm and 8mm

  • Water Inlet Tube

  • Drain Pipe

  • Diamond Cutting Wheel

  • Φ350 x 2.5 x Φ32mm

  • Water Tank and Pump and Operation Manual
