ASTM C39/C39M is the ASTM standard test method for determining the compressive strength of cylindrical concrete specimens. It is commonly used for molded concrete cylinders and drilled cores when strength results are needed for concrete quality control, specification compliance, mix evaluation, or investigation of in-place concrete.
This standard is centered on the compression test itself, so buyers usually need to consider the full lab workflow as well as the test frame. If you need help matching equipment capacity, platen setup, or specimen-end preparation options to your application, Contact Us.
ASTM C39/C39M Standard Test Method for Compressive Strength of Cylindrical Concrete Specimens
ASTM C39/C39M is a concrete compression test method. It covers determination of compressive strength for cylindrical concrete specimens such as molded cylinders and drilled cores.
In practical terms, this is one of the most commonly referenced standards when a project, plant, lab, or inspection program needs strength data from hardened concrete cylinders. The method is limited to concrete above the density threshold stated in the standard, so it should not be treated as a universal concrete strength method for every low-density material.
Quick Definition
ASTM C39/C39M describes how cylindrical concrete specimens are compression tested to produce a compressive strength result.
Document type: Standard test method.
Common specimens: Molded concrete cylinders and drilled concrete cores.
Common output: Compressive strength data used for concrete acceptance, process control, mix evaluation, and related engineering decisions.
Revision sensitivity: Equipment setup, loading control, specimen preparation, and reporting should match the exact cited edition.
What This Standard Covers
ASTM C39/C39M covers the compression testing step used to determine the strength of cylindrical concrete specimens. The method is used after the specimen has been made, cured, and prepared for testing under the applicable companion standards.
The scope is narrower than a full concrete testing program. It does not stand alone for specimen fabrication, field curing, laboratory curing, or end preparation, even though those steps strongly affect the result. For many labs, the most important takeaway is that ASTM C39/C39M governs the compressive test result, while companion standards govern how the specimen reaches the machine.
Why This Standard Matters in Testing
Compressive strength is one of the most widely used performance indicators in concrete testing. ASTM C39/C39M is important because it provides a consistent method for producing that result from cylindrical specimens.
The method is routinely used as part of concrete quality control and acceptance workflows. It also supports comparison of mixtures, review of placement quality, and evaluation of admixture effectiveness. Because concrete strength results can be influenced by specimen size, shape, sampling, molding, age, and curing history, the standard matters not only for the load application itself but also for keeping the test sequence consistent from specimen preparation through final break.
For acceptance testing of concrete cylinders, personnel qualification requirements can also matter, so laboratories often pair ASTM C39/C39M with broader agency and technician qualification requirements in their quality systems.
Common Materials, Product Types, or Applications Covered
ASTM C39/C39M is commonly applied to hardened concrete specimens used in construction and materials laboratories.
-
Field-cast cylinders taken from ready-mixed or site-placed concrete
-
Laboratory-made cylinders used for mixture development or comparative testing
-
Precast and cast-in-place concrete quality programs
-
Drilled cores taken from existing concrete when in-place strength information is needed
This page should be read as a cylindrical concrete strength-testing standard, not as a general standard for every concrete shape or every structural evaluation method.
Common Test or Verification Workflow
A typical ASTM C39/C39M workflow starts with concrete specimens that were produced or obtained under related standards, then moves into end preparation, dimensional checks, compressive loading, and strength calculation.
Common workflow: Make or obtain the cylindrical specimen, cure or condition it as required, prepare the specimen ends if needed, place the specimen in the compression machine, apply compressive load under the method requirements, and report the resulting strength.
In many laboratories, molded field specimens are prepared under ASTM C31/C31M, laboratory specimens under ASTM C192/C192M, drilled cores under ASTM C42/C42M, and specimen end preparation under ASTM C617/C617M or ASTM C1231/C1231M before the actual compression test is run under ASTM C39/C39M.
Because strength results are sensitive to specimen history, a consistent workflow is essential. Small differences in curing, moisture condition, specimen geometry, or end condition can materially affect the reported strength.
Equipment Commonly Used for This Standard
ASTM C39/C39M most directly points buyers toward concrete compression testing equipment rather than a broad universal mechanical testing setup.
Common equipment: Concrete compression testing machines or other suitable compression load frames, compression platens or bearing block assemblies, specimen measurement tools, data acquisition or controller systems, and safety features for fragment containment.
Many labs also need specimen-end preparation tools or accessories as part of the complete workflow. Depending on the lab procedure, that can include bonded capping materials and related equipment or unbonded cap systems used with hardened cylindrical specimens.
When selecting equipment for ASTM C39/C39M work, the practical questions usually involve load capacity, supported specimen sizes, platen configuration, lab throughput, data handling, guarding, and whether the system needs to support both routine cylinder testing and core testing.
How to Read This Designation or Revision
ASTM C39/C39M is the base designation for this standard. The C-prefix places it within ASTM concrete and aggregate standards, and the dual designation format indicates that SI and inch-pound units are both addressed in the document and must be handled as separate systems.
The year suffix identifies the edition being cited, and some years may also include a trailing letter to show a later revision within that year. In purchasing documents, project specifications, and lab procedures, it is important to match the exact cited edition rather than relying only on the base designation.
Practical caution: If a contract, DOT specification, owner requirement, or accreditation document cites a specific revision, the test setup and reporting package should follow that revision exactly.
Related Standards, Methods, or Frameworks
ASTM C39/C39M is usually part of a larger concrete strength-testing workflow rather than a stand-alone document.
Common related standards: ASTM C31/C31M for making and curing concrete test specimens in the field, ASTM C192/C192M for making and curing concrete test specimens in the laboratory, ASTM C42/C42M for obtaining and testing drilled cores of concrete, ASTM C617/C617M for capping cylindrical concrete specimens, ASTM C1231/C1231M for use of unbonded caps, and ASTM C1077 for testing agency and personnel qualification requirements tied to acceptance testing.
These related standards matter because a compression machine quote may need to address more than peak force. End-preparation method, specimen source, and reporting expectations can all influence the right equipment configuration.
Get Help with ASTM C39/C39M Equipment Selection
If you are planning a concrete compression testing system for ASTM C39/C39M, the right configuration usually depends on specimen size range, target strength range, throughput, platen setup, guarding, and whether your workflow also includes capping or unbonded cap accessories.
Request a Quote for a configuration matched to your ASTM C39/C39M concrete cylinder and core testing workflow.
